  • Bergey Windpower is the oldest and most experienced manufacturer of residential-sized wind turbines in the world.

    Thirty years ago Bergey pioneered the radically-simple “Bergey design” that has proven to provide the best reliability, performance, service life, and value of all of the hundreds of competitive products that have come and gone in that time. With only three moving parts and no scheduled maintenance necessary, the Bergey 10 kW has compiled a service record that no other wind turbine can match. We back it up with the longest warranty in the industry.
Product Portfolio
  • Turbines

  • Bergey wind turbines are available in two sizes, a 10 kW unit primarily used for reducing utility bills and a 1 kW primarily used for off-grid applications. Both models have been installed in thousands of sites around the world and are market leaders in performance and reliability. If you are looking for a wind turbine for your home the Bergey Excel-S is the model for you.
      • Bergey XL.1

      • With a rotor diameter of 2.5 meters (8.2 ft) and a peak output of approximately 1,300 watts the XL.1 is intended for the off-grid home market in the U.S., telecommunication sites, and for rural electrification programs in developing countries. It is also a perfect upgrade system for current owners of solar-only off-grid systems.
        Very quiet operation is achieved with advanced rotor design and an oversized alternator that reduces the rotor operating speed.

        - Off grid sites
        - Telecom sites.
        - Rural elecrification programs.

        Start-up Wind Speed 3 m/s (6.7mph) Type 3 Blade Upwind
        Cut-in Wind Speed 2.5 m/s (5.6 mph) Rotor Diameter 2.5 m (8.2 ft.)
        Rated Wind Speed 11 m/s (24.6 mph) Blade Pitch Control None, Fixed Pitch
        Rated Power 1000 watts Overspeed Protection AUTOFURL
        Maximun Power 1,300 watts Gearbox None, Direct Drive
        Cut-Out Wind Speed None Temperature Range -40 to +60 Deg. C (-40 to +140 Deg. F)
        Furling Wind Speed 13 m/s (29 mph) Generator Permanent Magnet Alternator
        Max. Design Wind Speed 54 m/s (120 mph) Output Form 24 VDC Nominal
      • Bergey Excel

      • The BWC EXCEL is a modern 7 meter (23 ft) diameter, 10,000W wind turbine designed for high reliability, low maintenance, and automatic operation in adverse weather conditions. It is available in two configurations: battery charging and grid-connected.

        - Large rural homes.
        - Remote villages and facilities.
        - Eco-tourism resorts.
        - Larger telecommunication sites.

        Start-up Wind Speed 3.4 m/s (7.5 mph) Cut-in Wind Speed 3 Blade Upwind
        Rated Wind Speed 2.5 m/s (5.6 mph) Rated Power 10 kW for grid intertie, 7.5 kW for battery-charging
        Cut-Out Wind Speed None Furling Wind Speed 15.6 m/s (35 mph)
        Max. Design Wind Speed 60 m/s (134 mph) Type 3 Blade Upwind
        Rotor Diameter 7 m (23 ft.) Blade Pitch Control None, Fixed Pitch
        Overspeed Protection AUTOFURL Temperature Range -40 to +60 Deg. C (-40 to +140 Deg. F)
        Gearbox None, Direct Drive Generator Permanent Magnet Alternator
    • Wind Turbine Products

        • Towers

        • Guyed Lattice (GL)
          Pro: Best value, Easy Install, with crane.
          Con: Uses Guy wires.
          Available Heights: 12-43m (40-140ft).
          10kw only.

          Tilt-up Guyed-Tubular
          Pro: Easy Install, without crane.
          Con: Uses Guy wires.
          Available Heights: 18-30m (60-100ft).
          1kw only.

          Self-Supporting Lattice (SSL)
          Pro: No Guy wires, Looks Good.
          Con: Higher costs.
          Available Heights: 18-49m (60-160ft).
          10kw only.

          Tilt-up Guyed-Lattice
          Pro: Lowers in hurrican or typhoon, Installs without crane.
          Con: Higher costs.
          Available Heights: 18-30m (60-100ft).
          10kw only.
        • Inverters

        • Sine-Wave Type Inverters
          These inverters are from Trace Engineering, Trace Technologies, and Advanced Energy Systems. The smaller units are standard products, while the larger system ( over ~ 20 kW) are usually custom ordered.

          Pro: Best power quality and features.
          Pro: Can control back-up generator.
          Con: More expensive than modified sine wave units.

          Modified Sine-Wave Type Inverters
          These inverters are from Trace Engineering.
          Pro: Lower costs
          Con: May cause noise and other problems with some loads.
        • Battery strings

        • Consumer Type
          These battery strings use the Trojan T-105 (220 AH) and L-16 (350 AH), or equivalent, deep-cycle flooded-cell lead-acid batteries. These batteries are recommended for most applications.
          Pro: Best value, Easier to transport (less heavy).
          Con: Requires frequent filling with distilled water.
          Con: Somewhat shorter expected cycle life.

          Commercial Type
          These battery strings use the GNB Re-Source Commander, or equivalent, deep-cycle flooded-cell lead-acid batteries.
          Pro: Larger AH capacities possible, Somewhat longer expected cycle life.
          Con: Requires filling with distilled water, Harder to transport.

          Industrial/ Telecom Type
          These battery strings use the GNB Absolyte IIP, or equivalent, deep-cycle gel-cell (sealed) lead-acid batteries.
          Pro: Maintenance-free,  Freeze-tolerance.
          Con: Expensive,  Harder to transport.
      • Wind Turbine Packages

          • 10 kW GridTek System

          • • 600- 2,000 Kilowatt-hours per month (depending on wind rescource).

            This system does not provide back-up power during utility power outages. It automatically shuts off to protect the safety of utility repair crews.

            • Homes or businesses that use at least 1,000 kWh's per month.

            • Property sizes of 1 acre or more

            • Wind Class 2 or higher

          • 10.1 kW Hybrid Systems

          • • 750 - 1,800 Kilowatt-hours (kWh's) per month (depending on wind and solar resources).

            Hybrid wind & solar systems provide more consistent year-round performance and reduce the need for back-up generation.
            This system provides more consistent year-round renewable energy production. These systems are modular and can be expanded easily.

          • 1.2 kW Hybrid System

          • • 80-200 Kilowatt-hours per month (depending on wind and solar rescources.

            Hybrid wind & solar systems provide more consistent year-round performance and reduce the need for back-up generation. We highly recommend wind and solar hybrids for smaller systems.

            This hybrid system provides more consistent year-round renewable energy production. These systems are modular and can be expanded easily.

          • 7.5 kW Remote System

          • • Large remote homes or facilities, using at least 700 kWh per month.

            • Locations where delivering or storing diesel fuel is a problem.

            • Retrofit to existing diesel-only power system to provide 24-hour power availability.

            • Wind Class 2 or higher.

            This system contains batteries and is typically used in conjunction with a back-up generator (gasoline, propane, or diesel fuel). These systems are modular and can be expanded easily.
          • 1 kW Remote System

          • • 60-150 AC Kilowatt-hours per month (depending on wind rescource).
            This system contains batteries and is typically used in conjunction with a back-up generator (gasoline, propane, or diesel fuel). These systems are modular and can be expanded easily.
          • 7.5 kW Home Sure System

          • • 400 - 1,500 Kilowatt-hours (kWh's) per month (depending on wind resource), 24 hours to over a week of back-up power (depending on load and wind).

            This system contains batteries and can provide essential household power during power outages.
          • 2 kW Home Sure System

          • • 160 - 300 Kilowatt-hours (kWh's) per month (depending on wind resource), 12 hours to over a week of back-up power (depending on load and wind).

            This system contains batteries and can provide essential household power during power outages.
          • 1 kW Pump System

          • • 2,000-8,000 gallons per day (depending on pumping and wind rescource).
            Hybrid wind & solar systems provide more consistent year-round performance and reduce the need for back-up generation.

        • Areas Of Application

            • Homes

            • Thousands of homeowners across the country are using a Bergey wind turbine to drastically cut their electric bills. Learn more about powering your home with the wind.
            • Farms & Small Business

            • A Bergey wind turbine will lower your operating costs and make a clear statement on your environmental stewardship. Learn more about powering your business with the wind.
            • Green Telecom

            • A Bergey wind turbine can greatly reduce your OPEX and environmental footprint at off-grid BTS/RBS sites. Learn more about powering your new and existing sites with the wind.
