- Offer Profile
- Sandvik Coromant is the world’s leading
supplier of tools, tooling solutions and know-how to the metalworking
industry. With extensive investments in research and development we create
unique innovations and set new productivity standards together with our
customers. These include the world's major automotive, aerospace and energy
industries.
Sandvik Coromant has 8,000 employees and is represented in 130 countries.
We are part of the business area Sandvik Machining Solutions within the
global industrial group Sandvik.
Product Portfolio
Turning tools
General turning
CoroTurn® 107
-
For internal turning and external turning of slender components
CoroTurn® 107 is the first choice for external and internal machining of small, long and slender components. Sharp cutting edges and excellent chip control ensure a soft cutting action and low cutting forces, providing an excellent surface finish to the component. Geometries designed for high pressure coolant is also available.
Benefits
- Improved chip control
- Low cutting forces
- Excellent edge strength
CoroTurn® 111
-
Internal turning with long overhangs or unstable conditions
CoroTurn® 111 is a versatile system with inserts geometries and grades for all materials. It is a real problem solver when you want to avoid vibrations at long overhangs and unstable conditions.
Benefits
- Secure insert clamping
- Excellent repeatability
- Free chip flow
- Low cutting forces
- Excellent edge strength
CoroTurn® HP
-
Advanced cooling technology
The CoroTurn® HP programme consists of a full range of tool holders with advanced cooling technology. The fixed nozzles in the tool holder promise improved chip control, process security and high productivity, due to jets perfectly directed at the cutting zone. In combination with dedicated insert geometries for high pressure coolant, the performance in terms of tool life can be increased.
Benefits
- Improved chip control
- Coolant precision ensures prolonged tool life in hard to machine materials
- Fast and easy insert indexing/change
- Process security
CoroTurn® RC
-
Rigid clamping for stability in productive turning.
CoroTurn RC is the first choice system for turning large components, from heavy roughing to finishing. It can also be used for internal turning of large diameter holes when the chip evacuation is good.
CoroTurn RC system is available as Coromant Capto cutting units and conventional shank design for all insert shapes and in different entering angles.
- Stability and security in productive turning
- Large product range of tools with different entering angles, insert shapes and sizes
- Insert geometries and grades for all materials
- Inserts with wiper technology
CoroTurn® SL
-
Modular tooling system of adaptors with exchangeable cutting heads
CoroTurn® SL is a universal modular system of adaptors with exchangeable cutting heads where you can build customized tools for a variety of machining applications.
Flexible tooling
The ingenious Serration Lock (SL) interface is extremely robust and lets you create a wide range of tool combinations from a small inventory of adaptors and cutting heads
Adaptors available for both internal and external machining
Reliable chip evacuation and long tool life
The high precision nozzles on the cutting heads put coolant exactly where you need it, for good chip breaking and long tool life
Tool wear is mainly on the exchangeable cutting head, extending the life of the adaptor
High machine utilization
Quick change with Coromant Capto®
Adaptors with internal coolant for efficient coolant supply
CoroTurn® TR
-
High precision profiling
To achieve the highest quality of profiles, the key is to prevent cutting forces from causing micro-movements of the insert. The stable iLock interface of CoroTurn® TR is developed to bridge this challenge, making it your first choice for external profiling.
Benefits
- High precision components and process security
- Stable insert clamping (iLock) ensures good repeatability and accuracy while allowing for high cutting data
- High precision coolant improves chip control and tool life
- Handling efficiency with QS shanks and Coromant Capto®
- Easy coolant connection and tool changes with plug and play adaptors or QS stops (QS shanks)
Heavy turning
T-Max® P
-
Negative basic-shape inserts for high performance turning
T-Max® P is your first choice for general turning, stretching from small components to heavy machining. The inserts fit into all Sandvik Coromant high performance holding systems and can be used in a variety of applications in all materials. Geometries specifically designed for high pressure coolant is now available for steel, stainless steel and HRSA materials.
Benefits
- Dedicated grades and geometries for all applications and materials
- Productive solution with wiper and Xcel technologies
- Supreme optimization possibilities with high pressure coolant insert geometries
- Reliable and secure machining, even in roughing applications
- Full range of clamping and coolant systems for all materials and applications
- Possibility to optimize by using dampened tools
Multi-task machining
CoroPlex® MT
-
Multifunctional milling and turning tool
CoroPlex® MT is a combination of two winning concepts in one – CoroMill® 390 and CoroTurn® 107. It is either applied rotating as an efficient tool for milling applications, or indexed in a number of optional positions for stationary turning, external and internal, using two different CoroTurn 107® inserts.
Benefits
- One milling and four turning tools in one
- Reduced tool changing time
- Saves tool pockets in tool magazine
- Stationary application as a turning tool, external or internal
CoroPlex® SL
-
Multi-functional tool for turning, threading, parting, and grooving
Build your own optimized multi-functional tool by combining a Coromant Capto® tool adaptor, a CoroPlex™ SL mini-turret adaptor and your choice of four cutting heads and blades for turning, threading, and grooving operations.
Benefits
- Four turning tools in one
- Reduces tool changing time
- Saves tool pockets in tool magazine
CoroPlex® TB
-
Combined turning and boring bar
CoroPlex TB is a combined turning and boring tool with two inserts in the same tool. The Sandvik Coromant advanced nozzle technology will give you excellent chip control and longer tool life. Thanks to the exact coolant jets, directed at the cutting zone of the insert, you gain the advantages even at lower pressures. Use the integrated turbo bars for turning centers and the modular SL couplings for large turning centers and multi-task machines.
Benefits
- Chip control and longer tool life
- Reduced set-up times with Coromant Capto®
- Quick tool changing for reduced machine downtime
- High pressure coolant
- Reduced maintenance and downtime costs
CoroPlex® TT
-
Two turning tools in one
CoroPlex TT is a twin tool with great flexibility. With two turning inserts on the same tool, substantial tool changing time is saved. CoroPlex TT gives you a variety of solutions for most turning operations.
Benefits
- One milling and four turning tools in one
- Reduced tool changing time
- Saves tool pockets in tool magazine
CoroTurn® SL
-
Modular tooling system of adaptors with exchangeable cutting heads
CoroTurn® SL is a universal modular system of adaptors with exchangeable cutting heads where you can build customized tools for a variety of machining applications.
Flexible tooling
The ingenious Serration Lock (SL) interface is extremely robust and lets you create a wide range of tool combinations from a small inventory of adaptors and cutting heads
Adaptors available for both internal and external machining
Reliable chip evacuation and long tool life
The high precision nozzles on the cutting heads put coolant exactly where you need it, for good chip breaking and long tool life
Tool wear is mainly on the exchangeable cutting head, extending the life of the adaptor
High machine utilization
Quick change with Coromant Capto®
Adaptors with internal coolant for efficient coolant supply
Parting and grooving
CoroCut® 1-2
-
Efficient parting and grooving
With easily connected over- and under coolant on all tools, together with an extremely rigid spring clamping mechanism, CoroCut 1-2 ensures truly secure and efficient machining. The system covers all parting and grooving applications in most materials, from standardized grooves to parting off and profiling in heat resistant super alloys.
Secure and efficient machining
- Over- and under coolant for good chip evacuation, less tool wear and a more stable performance
- Patented spring clamping mechanism for a rigid and accurate insert clamping, which allows for increased feed rate
- Strong tool material alloy for high fatigue resistance
CoroCut® 3
-
Economical shallow parting, grooving and profiling
CoroCut® 3 is a complete solution for narrow precision grooving and circlip grooving. It is your first choice for cost efficient parting-off in mass production – you can save kilometers of material by reducing the insert width with CoroCut 3.
Benefits
- Precision grooving down to the smallest widths
- Maximum versatility – one holder for all insert widths
- Cost efficient due to three cutting edges
- Stabile interface
CoroCut® MB
-
For internal machining of high precision components
CoroCut® MB is a high precision system for grooving, face grooving, profiling and pre-parting. The edge line of the cutting edge is sharp with a thin-layered coating, which in combination with the stability of the tools makes it ideal for internal machining.
Benefits
- Vibration free machining
- Fast set up for both tool and insert
- Stable high precision interface between interface and tool holder
CoroCut® QD
-
The most reliable system for parting off
When you need to machine deep grooves or part off in long overhangs, CoroCut® QD is the safest choice. All tools have over- and under coolant for best performance and chip control. Add the support from plug and play coolant adaptors and a stable, user-friendly clamping mechanism and you get CoroCut QD – a system to rely on
CoroCut® XS
-
Versatile small part machining system for external applications
CoroCut® XS is a tangentially mounted system for precision machining in sliding head machines. The system is for external parting, grooving, turning, backturning and threading applications. The extremely sharp cutting edges perform best at low feeds.
Benefits
- High precision
- Close tolerances
- Easy indexing
- Good accessibility when changing inserts
- Wide variety of insert widths
- Internal grooving at very small diameters
CoroThread® 254
-
For circlip grooving and other shallow grooves
CoroThread® 254 is your first choice for demanding external and internal grooving operations. The slotted insert sits rigidly on the T-rails in the pocket eliminating any insert movement caused by the cutting force variations.
Benefits
- High indexing repeatability
- Stable solution with low risk of vibrations
- Cost efficient solution with three cutting edges
- Easy clamping of new inserts due to the iLock interface
CoroTurn® SL
-
Modular tooling system of adaptors with exchangeable cutting heads
CoroTurn® SL is a universal modular system of adaptors with exchangeable cutting heads where you can build customized tools for a variety of machining applications.
Flexible tooling
The ingenious Serration Lock (SL) interface is extremely robust and lets you create a wide range of tool combinations from a small inventory of adaptors and cutting heads
Adaptors available for both internal and external machining
Reliable chip evacuation and long tool life
The high precision nozzles on the cutting heads put coolant exactly where you need it, for good chip breaking and long tool life
Tool wear is mainly on the exchangeable cutting head, extending the life of the adaptor
High machine utilization
Quick change with Coromant Capto®
Adaptors with internal coolant for efficient coolant supply
CoroTurn® XS
-
Internal machining of small high quality features
CoroTurn XS precision ground tools are perfect when producing small internal features with high quality. The large variety of adaptors fit most types of sliding head machines and the solid carbide boring bars are designed for exact cutting edge position, enabling high precision and repeatability.
Benefits
- Optimized for machining of small high quality features
- High precision and repeatability
- Reliable and easy-to-use clamping system
T-Max Q-Cut®
-
Internal grooving and small diameter face grooving
T-Max Q-cut® is a universal single edge system for parting off, grooving and internal face grooving, suitable for parting off large components and deep grooving applications.
Benefits
- Excellent surface finish due to wiper technology
- Proven, versatile system
- Large variety of widths
Silent Tools
Silent Tools for turning
-
Overcome vibrations in internal turning
Silent Tools dampened boring bars and adapters make it possible to maintain good productivity and close tolerances also for long tool overhangs beyond 3 x bar diameter. Silent Tools dampened steel bars make it possible to machine up to 10 x bar diameter, and our dampened carbide reinforced bars go even higher; up to 14 x bar diameter tool overhang.
Benefits
- Productivity gains: 50% for shorter boring bars and up to 400% for longer overhang lengths
- Improved surface finish
- Improved process security
- Improved chip evacuation
- Reduced cost per component
Small part machining
CoroCut® 1-2
-
Efficient parting and grooving
With easily connected over- and under coolant on all tools, together with an extremely rigid spring clamping mechanism, CoroCut 1-2 ensures truly secure and efficient machining. The system covers all parting and grooving applications in most materials, from standardized grooves to parting off and profiling in heat resistant super alloys.
Secure and efficient machining
- Over- and under coolant for good chip evacuation, less tool wear and a more stable performance
- Patented spring clamping mechanism for a rigid and accurate insert clamping, which allows for increased feed rate
- Strong tool material alloy for high fatigue resistance
CoroCut® MB
-
For internal machining of high precision components
CoroCut® MB is a high precision system for grooving, face grooving, profiling and pre-parting. The edge line of the cutting edge is sharp with a thin-layered coating, which in combination with the stability of the tools makes it ideal for internal machining.
Benefits
- Vibration free machining
- Fast set up for both tool and insert
- Stable high precision interface between interface and tool holder
CoroCut® XS
-
Versatile small part machining system for external applications
CoroCut® XS is a tangentially mounted system for precision machining in sliding head machines. The system is for external parting, grooving, turning, backturning and threading applications. The extremely sharp cutting edges perform best at low feeds.
Benefits
- High precision
- Close tolerances
- Easy indexing
- Good accessibility when changing inserts
- Wide variety of insert widths
- Internal grooving at very small diameters
CoroThread® 254
-
For circlip grooving and other shallow grooves
CoroThread® 254 is your first choice for demanding external and internal grooving operations. The slotted insert sits rigidly on the T-rails in the pocket eliminating any insert movement caused by the cutting force variations.
Benefits
- High indexing repeatability
- Stable solution with low risk of vibrations
- Cost efficient solution with three cutting edges
- Easy clamping of new inserts due to the iLock interface
CoroThread® 266
-
Ultra-rigid thread turning for all types of threads – internal and external
CoroThread® 266 is designed with an iLock interface to combat the extreme forces placed upon the insert in the threading operations. The tool guarantees excellent insert stability for ultimate accuracy, surface finish and product consistency.
Benefits
- Reduced machine- and downtime
- Excellent surface finish due to the exceptional stability
- High product consistency
- Three sharp cutting edges for high-quality threads
- Multi-point inserts available, require fever passes resulting in increased productivity
CoroTurn® 107
-
For internal turning and external turning of slender components
CoroTurn® 107 is the first choice for external and internal machining of small, long and slender components. Sharp cutting edges and excellent chip control ensure a soft cutting action and low cutting forces, providing an excellent surface finish to the component. Geometries designed for high pressure coolant is also available.
Benefits
- Improved chip control
- Low cutting forces
- Excellent edge strength
CoroTurn® XS
-
Internal machining of small high quality features
CoroTurn® XS precision ground tools are perfect when producing small internal features with high quality. The large variety of adaptors fit most types of sliding head machines and the solid carbide boring bars are designed for exact cutting edge position, enabling high precision and repeatability.
Benefits
- Optimized for machining of small high quality features
- High precision and repeatability
- Reliable and easy-to-use clamping system
QS™ holding system
-
Get more out of your sliding head machine
QS™ holding system is a quick change tool holder for maximized machine utilization in sliding head machines. The system is available with high precision coolant for excellent process security.
Easy tool change for reduced downtime
- Single screw release of holder simultaneously pulls out the wedge, for easy tool change and set-up
- Spring clamping mechanism of the wedge eliminates the risks of tool holder dropping into the machine
- No diameter adjustment is necessary thanks to the back stop – close repeatability tolerance for insert edge position
- QS holding system can be quickly mounted on the machine with no reconstruction
Milling tools
Face milling
Auto AF
-
Face milling cutter
Adjustable face milling cutter for finishing cast iron components, demanding high quality surface finishes.
Benefits
- Fully adjustable face milling cutter for best surface finishing
- Cassette solution with possibility to use both N260.8 inserts and cassettes for CoroMill® 245 inserts
- High-productive finishing cutter for the automotive industry
Auto FS
-
Square shoulder face mill
Fixed pocket face milling cutter designed for square shoulder cast iron applications demanding fine surface finishes at high feed rates.
Benefits
- Spring clamp system for quick and easy insert change
- Extra close pitch for high productivity in face and square shoulder milling
- Close tolerance cutter for superior finishing
Auto Roughing
-
Face milling cutter
Extra close pitch face milling cutter primarily intended for roughing and semi-finishing of cast iron components.
Benefits
- Spring-loaded insert for quick and easy insert indexing
- High-productive auto roughing cutter
- Strong triangular insert
CoroMill® ® 210
-
High feed face and plunge milling
The CoroMill® 210 is a very productive roughing concept to use when high metal removal rate is the first priority. A 10° entering angle allows extreme feed rates when face milling. This directs the cutting forces in an axial direction which provides a stable cutting action and no vibration tendency.
Benefits
- High table feed due to the chip thinning effect – high productivity
- First choice face milling cutter in long overhang machining
- Multipurpose tool. Face milling, boring possibilities, ramping and plunge milling
CoroMill® ® 245
-
Light-cutting face mill for heavy roughing and mirror finishing
Milling cutters for high metal removal and mirror finish. The cutter is designed with enhanced corners to reduce burr formation and frittering of the component.
Benefits
- Easy to use and high productivity
- Light cutting with low power consumption
- Close tolerance combined with the wiper insert for superior surface finish
- Wide range of grades and geometries including ceramic and CBN grades
CoroMill® ® 345
-
Face mill for high productivity
CoroMill® 345 is a cost-efficient face mill for high productivity in terms of feed per tooth and metal removal rate. The robust cutter body and shim-protected tip seats give security to the machining process, making the cutter body a good choice if unmanned production is a priority.
Benefits
- Low cost per component thanks to eight cutting edges
- High output – with internal coolant high productivity is possible also in demanding materials
- Secure machining thanks to shim-protected tip seats and tough cutter body
- Optimized machine utilization and productivity with four different pitches
- Wide application area – use the same concept for different applications
CoroMill® ® 357
-
Multi-edge rough face milling cutter
CoroMill® 357 is a multi-edge face milling cutter for roughing and cubing in mainly steel and cast iron. It has a secure and strong cutter body design with shim-protected tip seats and a clamping system that offers quick and easy insert indexing.
Benefits
- High metal removal rate
- Low downtime thanks to inserts that are easy to index and change, even with gloves on
- Reliable performance
- Cost-efficient solution with multi-edge design
CoroMill® ® 360
-
Heavy duty face mill
With a maximum cutting depth of 18 mm (0.709 inch) together with high feed per tooth, CoroMill® 360 provides a productivity boost that is tough to beat, with minimum risk for failure and machine downtime.
Benefits
- Same tool body can use two different cassette types for insert with IC 19 mm (0.748 inch) and IC 28 mm (1.102 inch)
- Exchangeable insert cassettes with serrated interfaces provide for safe, accurate location and easy handling
- Separate cassettes for each insert size for use in the same cutter body reduces down time and inventory
CoroMill® ® 365
-
Secure face milling in cast iron and steel
CoroMill® 365 is the essential tool for rough to semi-finish face milling of cast iron and steel components. Use the tool for large series production and applications where high metal removal rate is critical.
Benefits
- Inserts with ability to machine down to AP = 6 mm (0.236 inch)
- Unique design with eight true cutting edges for high productivity machining to achieve low cost per component
- Multi-edge self-located insert provides robust and reliable machining
- The higher density of inserts in the cutter body means that higher table feeds can be implemented to give exceptional manufacturing economy
CoroMill® ® Century
-
Light cutting face mill for high speed finishing
CoroMill® Century is a face mill tool system with aluminium or steel body for high speed machining. The tool is designed with serrated insert interface for safe performance and reduced run-out. The axial position of the inserts can easily be micro set with high accuracy.
Benefits
- High speed machining security by design
- Intensified chip evacuation through accelerated cutting fluid
- Easy setting to micro precision within 0.1 mm (0.0039 inch) setting range
CoroMill® ® S-60
-
Multi-edge face milling cutter
CoroMill® S-60 is a close-pitch cutter for machining in cast iron. The close pitch and high number of cutting edges increase productivity and reduce costs.
Benefits
- Close and extra-close pitch cutters for great productivity and long tool life
- Low production costs
- Short set-up time
- Wiper option for brilliant surface finish
- Easy to handle, no need to remove screws when indexing insert
T-Max® 45
-
High metal removal in powerful machines
45° entering angle and strong inserts enable machining under demanding conditions and at long overhangs. Large parallel lands and secondary cutting edges provide effective back-cutting facility.
Benefits
- Spring-loaded insert clamping system for quick and easy insert change
- Possibility to adjust the axial run-out within 5 micro for close tolerance machining
Gear milling
CoroMill® ® 161
-
InvoMilling™ cutters for module 2–4 mm (DP 12.70–6.35)
Gear milling with the CoroMill® 161 precision cutters, optimized for InvoMilling, is very flexible since the same tools are used for different gear profiles. This means that machining can start right away instead of having to wait for an engineered tool, ideal when machining small batches and when short lead times are a priority.
Flexibility
Use the same cutters for many different gear profiles
Small tool inventory
Short total manufacturing time
Start machining right away – no need to wait for a gear profile specific tool
Complete components in one set-up
Gear quality according to DIN 6
The robust cutters are designed to adhere to the requirements of the InvoMilling process and give very accurate gears
CoroMill® ® 162
-
InvoMilling™ cutters for module 4–12 mm (DP 6.35–2.12)
Gear milling with the CoroMill® 162 precision cutters, optimized for InvoMilling, is very flexible since the same tools are used for different gear profiles. This means that machining can start right away instead of having to wait for an engineered tool, ideal when machining small batches and when short lead times are a priority.
Flexibility
Use the same cutters for many different gear profiles
Small tool inventory
Short total manufacturing time
Start machining right away – no need to wait for a gear profile specific tool
Complete components in one set-up
Gear quality according to DIN 6
The robust cutters are designed to adhere to the requirements of the InvoMilling process and give very accurate gears
CoroMill® ® 170
-
Rough gear milling with precision
CoroMill® 170 is a high performance cutter for large gears in module range 12-22. In combination with our latest grades, CoroMill 170 will cut time in your gear machining, leaving minimal and even allowance for subsequent operations. Use it for precision and reliability in roughing external and internal gears.
CoroMill® ® 171
-
Quick and easy gear milling
The CoroMill® 171 cutters for small modules are easily applied in machining centres, multi-task machines and turning centres, making it possible to machine complete components in one set-up. Gears and splines made in hobbing machines or sub-contracted out can instead be machined in your own workshop using existing machines.
Complete components in one set-up
Gear milling in machining centres, multi-task machines and turning centres
Low investment costs
Machine gears in existing machines instead of investing in a hobbing machine
Less time and cost spent on logistics
No need to move components between machines or workshops
No need to re-sharpen and re-coat high speed steel (HSS) tools
CoroMill® ® 172
-
Gear milling made easy
The CoroMill® 172 disc cutter offers a versatile and timesaving solution for milling of high-quality gear profiles. Thanks to the new indexable carbide insert technology and a powerful iLock interface, the component can be machined in flexible non-dedicated machines, such as multi-task machines and machining centres, as well as in hobbing machines.
CoroMill® ® 176
-
A productive alternative to HSS tools
An innovative indexable insert cutter for productive gear wheel machining.
CoroMill® 176 is a more cost-efficient alternative to regrindable HSS (high speed steel) tools and is designed for gears in the module range 4 to 10. Its ability to reach higher cutting speeds combined with user-friendly insert changing will reduce cycle times, making it the high productivity gear milling choice.
CoroMill® ® 177
-
Versatile gear milling
CoroMill® 177 is an indexable carbide insert hob for large gear wheels. The new hobbing concept is optimized for high productivity when manufacturing gear wheels used in gear boxes and transmissions for wind power and other heavy industry applications. The polygon-shaped interface between the segments ensures precision and high torque transfer capability.
Benefits
- Secure and stable insert seats give reliable performance
- Easy and accurate insert mounting with easy-accessible insert screws
- Long tool life and low cost per component thanks to state-of-the-art carbide grades
- Cutter body that can be used for both roughing and finishing applications for excellent versatility
Finishing disc cutters
-
Finished gears in one pass
This finishing disc cutter creates gear profiles with involute forms with or without protuberance on internal and external gear wheels. Ground inserts adapted to the gear tooth profile will generate high precision results. And thanks to high performance insert grades and geometries, you can use the tools for both roughing out the majority of the material in the tooth gap and for creating a quality profile finish.
Benefits
- Short machining time since the same tool can do both roughing and finishing
- Variety of high-performance insert grades available
- Reliable and predictable performance with very good tool life
Double disc cutters
-
For large external gears
This tool is designed for productive rough machining of large external gear wheels. Comprising two disc cutters (that you can also use separately), it can even be designed so that the same two discs can machine components with different module sizes – a very smart solution if you have components in the same module range.
Benefits
- Same tools for several module sizes
- Productive solution for high metal removal rates
Duplex disc cutters
-
For large internal gears
This high-precision tool is adapted for finish machining applications of large internal gear wheels when maximum productivity is a priority. Both the tool and its inserts will be designed for your specific involute gear profile.
Benefits
- Highly productive with double discs
- Finished profile in one pass
High feed milling
CoroMill® ® 210
-
High feed face and plunge milling
The CoroMill® 210 is a very productive roughing concept to use when high metal removal rate is the first priority. A 10° entering angle allows extreme feed rates when face milling. This directs the cutting forces in an axial direction which provides a stable cutting action and no vibration tendency.
Benefits
- High table feed due to the chip thinning effect – high productivity
- First choice face milling cutter in long overhang machining
- Multipurpose tool. Face milling, boring possibilities, ramping and plunge milling
CoroMill® ® 316
-
The exchangeable-head milling system
Versatile in the widest sense of the word, CoroMill® 316 can be applied for high feed face milling, slot milling, helical interpolation, shoulder milling, profile milling and chamfer milling of components in all material groups from ISO P to ISO S.
The exchangeable milling heads allow you to quickly, easily and accurately switch between various operations. With a quick tool change you are able to get the perfectly suited end mill type, radius variation, teeth frequency, geometry and grade. CoroMill® 316 end mills are even suitable for five axis milling of flanks which often require tapered tools for stability at longer tool reach.
Benefits
- CoroMill 316 is an exchangeable head milling system for greater flexibility and better productivity plus lower tool and inventory costs
- A strong cutting head and shank interface provides high strength for roughing and high rigidity for finishing
- Higher stiffness and less deflection make it possible to machine long overhangs and deep pockets, as well as allowing higher accuracy in finishing operations
- Internal coolant on selected assortment delivers superior chip evacuation and a secure cutting process
CoroMill® ® 419
-
High-feed milling cutter
CoroMill® 419 is a high-feed milling concept with five edges for roughing to semi-finishing. It offers excellent performance in many material groups and has great possibilities for optimization. The high feed and light-cutting action enable a soft sound, creating an operator-friendly environment.
CoroMill® ® Plura
-
Solid end mills, tipped end mills and thread mills
In our comprehensive range of CoroMill® Plura end mills, you find your choice, whether you need a tool that is optimized for a specific material or one that performs well in many materials.
The range of tools includes high-performance solutions for high speed machining, die-making and high feed machining; from heavy roughing to super-finishing in most materials, whether it is in difficult-to-cut materials or very hard steels, up to 63 HRc.
The CoroMill Plura offer
-
Optimized tools with geometries and grades for specific materials and applications, maximizing production output per time unit.
- Flexible tools designed for high performance and secure machining in a variety of materials, applications, component sizes and shapes, allowing maximum machine utilization.
Parting and grooving
CoroMill® ® 327
-
Groove- and thread milling cutters
A versatile cutter which can be used for many types of grooves, threads and chamfers; machining of eccentric components such as gearbox casings, and high volume assemblies, mainly in machining centres and rotating units in lathes.
Benefits
- Low cutting forces
- Sharp cutting edges for high quality grooves without burr
- Multiple edges for highly productive and economic machining
- Large programme with different shank lengths and diameters
- Large programme of inserts covering for instance circlips, o-rings, slots and threads
CoroMill® ® 328
-
Grooving, threading and circlip grooving
A versatile cutter which can be used for many types of grooves, threads and chamfers; machining of eccentric components e.g. gearbox casings, and high volume assemblies, mainly on machining centres and rotating units on lathes.
Benefits
- Inserts mounted in pockets for safe and stable mounting
- Economical insert with three edges
- Large programme of inserts covering circlips, slots, threads, etc.
- Low cutting forces
- Sharp precision-ground insert
- Different thread pitches possible with one tool
- Excellent for both internal and external machining
CoroMill® ® 329
-
Groove milling cutter for accurate slots and high speed capability
Grooving cutter CoroMill® 329 adds speed and feed capability to groove milling thanks to the rigidity of CoroCut® V-rail interface plus the economy of CoroCut® two cutting edges.
Benefits
- Inserts are absolutely securely mounted with Corocut insert clamping
- High productivity due to many inserts in the cutter
- Low cutting forces
CoroMill® ® 331
-
Multi-purpose side and face milling cutter
The CoroMill® 331 is a multi-purpose side and face cutter with high-precision capability for numerous operations. The cutter is the most productive of its kind for producing slots and for cutting off. Wide slots can be produced by several CoroMill cutters mounted together in a gang.
Benefits
- Wide range of mounting options
- Open pockets
- Flexibility
- Good chip evacuation
- Wedge type cassette locking
- Accuracy, security and stability due to serrations
T-Max® Q-cutter
-
Slitting cutter for parting off and deep and narrow grooves
T-Max® Q-cutter is a universal system suitable for parting off large components and deep grooving applications.
Benefits
- Large programme
- Light-cutting
- Provides a plain bottom of the groove
Features
- Bore with keyway mounting
- Positive geometry
- Insert geometries and grades for all materials
CoroMill® ® QD
-
Groove milling and parting off
The main challenge in groove milling is usually chip evacuation. Chip issues often harm production efficiency, lower component quality or cause tool breakage, especially when machining narrow and deep grooves. With CoroMill® QD, there is a groove milling solution with the reliability needed for secure and trouble-free production processes.
Benefits
- Secure machining due to great reliability
- Quality grooves without chip issues
- Long and predictable insert- and cutter body tool life
- Easy and efficient insert changes
Profile milling
CoroMill® ® 200
-
Robust face milling and profile cutter
CoroMill 200 is a very stable rougher and a versatile tool. It is a good choice for general milling as well as for die and mould-making and should be the first choice for roughing operations. Strong cutting edges make the cutter resistant to tough conditions with interruptions (holes, gaps etc.) and/or abrasive scale (skin).
Benefits
- Process security and reliability
- High metal removal rate
CoroMill® ® 210
-
High feed face and plunge milling
The CoroMill® 210 is a very productive roughing concept to use when high metal removal rate is the first priority. A 10° entering angle allows extreme feed rates when face milling. This directs the cutting forces in an axial direction which provides a stable cutting action and no vibration tendency.
Benefits
- High table feed due to the chip thinning effect – high productivity
- First choice face milling cutter in long overhang machining
- Multipurpose tool. Face milling, boring possibilities, ramping and plunge milling
CoroMill® ® 216
-
A metal remover for rough and semi-finish profiling
CoroMill® 216 is a robust ball nose end mill for roughing and semi-finishing of curved surfaces. The tools are easy to apply in machining centres, CNC milling machines, and copy-milling machines for die and mould, aerospace, automotive, and associated industries.
Benefits
- Maximum security and reliability
- High metal removal rate
- Easy to apply
CoroMill® ® 216F
-
End mill for high-finish profiling
The CoroMill® 216F cutter is used for finish milling of a range of materials used for die and mould-making, as well as for manufacturing of turbine blades within the aerospace industry. Its sharp edges cut hardened steel up to HRC 60 along with stainless steel, grey- or nodular cast iron, and aluminium.
Benefits
- High precision
- Excellent surface finish
- Cost effective compared to solid carbide solutions
- Easy to apply
CoroMill® ® 300
-
Light cutting face and profile milling cutters
CoroMill® 300 is a round insert cutter for a broad range of operations such as face milling, pocketing, and profiling. Its light cutting action allows for smooth entries and exits and for use of extended tool set-ups.
The cutters generate low cutting forces and little heat when machining with small depths of cut. This allows the table feed to be increased five to ten times compared to general machining.
Benefits
- Universal product with a wide application window
- Large assortment covering many applications
- Cutters with positive design have light cutting action and generates low cutting forces, which allows for extra close pitched face mill versions with small inserts for high productivity at high speeds combined with high table feeds
- End mills with great accessibility and cutting action in all feed directions for multi-axis machining of complicated forms
CoroMill® ® 600
-
High-performance blade milling cutter
CoroMill® 600 is a modern innovative milling cutter – a completely new design based on our unique iLock™ insert clamping solution.
Developed for roughing and semi-finishing of turbine blades for power generation, this round-insert cutter enables a new approach to meet the challenges of blade machining.
Benefits
- Improved tool life and increased productivity in blade milling applications
- Easy and accurate insert indexing (possible with gloves) – no need to remove screw to index the insert
- Able to run at higher cutting speeds without vibration
- Cutter design enables ramping
- Insert geometry minimizes heat in the cutting zone and reduces power consumption
Round tools milling
CoroMill® ® 316
-
The exchangeable-head milling system
Versatile in the widest sense of the word, CoroMill® 316 can be applied for high feed face milling, slot milling, helical interpolation, shoulder milling, profile milling and chamfer milling of components in all material groups from ISO P to ISO S.
The exchangeable milling heads allow you to quickly, easily and accurately switch between various operations. With a quick tool change you are able to get the perfectly suited end mill type, radius variation, teeth frequency, geometry and grade. CoroMill® 316 end mills are even suitable for five axis milling of flanks which often require tapered tools for stability at longer tool reach.
Benefits
- CoroMill 316 is an exchangeable head milling system for greater flexibility and better productivity plus lower tool and inventory costs
- A strong cutting head and shank interface provides high strength for roughing and high rigidity for finishing
- Higher stiffness and less deflection make it possible to machine long overhangs and deep pockets, as well as allowing higher accuracy in finishing operations
- Internal coolant on selected assortment delivers superior chip evacuation and a secure cutting process
CoroMill® ® Plura
-
Solid end mills, tipped end mills and thread mills
In our comprehensive range of CoroMill® Plura end mills, you find your choice, whether you need a tool that is optimized for a specific material or one that performs well in many materials.
The range of tools includes high-performance solutions for high speed machining, die-making and high feed machining; from heavy roughing to super-finishing in most materials, whether it is in difficult-to-cut materials or very hard steels, up to 63 HRc.
The CoroMill Plura offer
- Optimized tools with geometries and grades for specific materials and applications, maximizing production output per time unit.
- Flexible tools designed for high performance and secure machining in a variety of materials, applications, component sizes and shapes, allowing maximum machine utilization.
Chamfer milling
CoroMill® ® 326
-
Internal threading and chamfering in small holes
Versatile and cost efficient, this miniature milling cutter benefits from three cutting edges for internal threading and chamfering. Use it in small holes, down to 6 mm (0.236 inch) as a complement to CoroMill 327, CoroMill 328 and CoroMill Plura.
Benefits
- Three cutting edges for productivity
- Chamfering and back-chamfering of holes with one tool
- Very high precision and low cutting forces
- Same tool for different pitches
- One grade for all materials
CoroMill® ® 327
-
Groove- and thread milling cutters
A versatile cutter which can be used for many types of grooves, threads and chamfers; machining of eccentric components such as gearbox casings, and high volume assemblies, mainly in machining centres and rotating units in lathes.
Benefits
- Low cutting forces
- Sharp cutting edges for high quality grooves without burr
- Multiple edges for highly productive and economic machining
- Large programme with different shank lengths and diameters
- Large programme of inserts covering for instance circlips, o-rings, slots and threads
CoroMill® ® 495
-
Versatile chamfer cutter
Most components require at least one chamfer operation. This makes frequent tool changes a potential problem, especially when machining small batches in different materials. With CoroMill 495®, the same tool can perform multiple kinds of chamfering in several materials, ideal for keeping downtime low and machine utilization high.
Benefits
- Versatile tool for many different chamfer operations
- Flexible inserts capable to perform in several workpiece materials
- High machine utilization thanks to few tool changes
Shoulder milling
CoroMill® ® 290
-
General-purpose square shoulder milling cutter
CoroMill® 290 is a general-purpose square shoulder milling cutter that provides an economical solution with four cutting edges per insert. It is also suitable for face milling when workpiece fixturing limits the approach for machining. Generally, it provides an economical solution with four cutting edges per insert but does not allow ramping.
Benefits
- Economical solution
- Long, even and predictable tool life
- Excellent surface finish
CoroMill® ® 390
-
Smooth shoulder milling and ramping
The CoroMill® 390 family covers many applications with a large, versatile programme, including cutter versions for shoulder milling and long edge milling. The cutter generates a good quality 90-degree shoulder and is ideal for ramping and helical interpolation.
Benefits
- Large depth of cut and steep ramping capability
- Versatile programme that covers a wide range of applications
- Close tolerances giving excellent surface finish and minimal mismatch
- Available in a shorter version for turning centres
CoroMill® ® 490
-
Face and shoulder mill for precise profiles
CoroMill® 490 gives true 90-degree cuts without sharp steps. It uses four-edge inserts with light cutting action, a result of innovative insert geometry in combination with high performance grades. Since the tool produces a smooth profile the need for finishing is efficiently reduced.
Benefits
- Great flexibility, high precision and good tolerances
- Light and quiet cutting with low cutting forces
- High productivity with outstanding insert geometry and new grades
- Sharp edge lines and burr-free, smooth profiles
- Component feature finished in one pass
- True 90-degree cut without sharp steps
CoroMill® ® 690
-
The cutting edge for titanium milling
CoroMill® 690 is developed specifically for high-productivity 2D profile milling of titanium components. Inserts are securely fastened by iLock technology. By equipping every insert pocket with threaded coolant holes with nozzles for high pressure coolant delivery, you can apply maximum coolant where required.
Benefits
- High-productivity milling of titanium
- ILock interface gives a secure process, increased feed and longer tool life
CoroMill® ® 790
-
Shoulder milling cutters for aluminium
The CoroMill® 790 cutter is the first choice for ISO N materials. To be used in shoulder operations as a "super remover", it is designed for high security demands and high precision work.
Benefits
- High speed machining performance with high security
- Extreme metal removal rates
- Very small tool run-out
CoroMill® ® Century
-
Light cutting face mill for high speed finishing
CoroMill® Century is a face mill tool system with aluminium or steel body for high speed machining. The tool is designed with serrated insert interface for safe performance and reduced run-out. The axial position of the inserts can easily be micro set with high accuracy.
Benefits
- High speed machining security by design
- Intensified chip evacuation through accelerated cutting fluid
- Easy setting to micro precision within 0.1 mm (0.0039 inch) setting range
Silent Tools
Silent Tools for milling
-
Boost your productivity
Many components and machine tools require long tool assemblies to reach down in large components. Vibration risk is high and the remedy is either slow machining or dampened tools.
With Silent Tools, chatter and vibration are eliminated, the machining rate can be increased and process security improved.
Benefits
- Productivity gains of at least 50% for the shortest adaptor lengths and up to 300% for longer adaptors
- Improved surface finish
- Improved process security
- Modular assemlies for required reach lengths
- Broad functionality range to cover all materials and application
Drilling tools
Deep hole drills
CoroDrill® ® 800
-
Deep hole machining system
In deep hole machining, a combination of tool design and cutting fluid pressure is used to evacuate the chips out of the hole. Both the Single tube system and Ejector drill system can produce holes with excellent surface finish, close dimensional tolerance and concentricity. CoroDrill® 800 with central insert L-geometry adds to excellent chip formation and evacuation.
Benefits
- Excellent surface finish
- Process security
- Few spare parts
- Good concentricity
- Excellent chip control and evacuation thanks to central insert L-geometry
CoroDrill® ® 801
-
Setting the standard in deep hole machining
CoroDrill® 801 enables a secure machining process in difficult to chip materials. With a rigid design and the latest insert and pad technology, it offers high process security and excellent chip control in large hole diameters.
Benefits
- High machine utilization
- Improved flexibility due to larger radial adjustability
- High availability due to a large standard programme
- Easy to apply
- Low noise level
- Excellent chip control and evacuation thanks to central insert L-geometry
CoroDrill® ® 808
-
Deep hole machining concept for STS system
CoroDrill® 808 is a deep hole machining concept designed especially for the STS system. Among many great features, this product is equipped with optimized pad design for good hole finish, unique edge preparation for increased chip breaking and a reinforced periphery insert corner for added security and reliability.
Suitable for diameters from 15.60 to 65.00 mm (0.614−2.559 inch) and tolerance demands of IT 9, CoroDrill 808 is capable of producing perfect holes, regardless of the component material.
First choice for close tolerance holes
Meets tolerance demands of IT 9
High process security
Long and predictable tool life guarantees high process security
High toughness and excellent wear resistance thanks to TiAIN coated grade
Excellent chip breaking
Insert geometry optimized for excellent chip breaking
CoroDrill® ® 818
-
Exceeds your expectations in counterboring
CoroDrill® 818 is a new counterboring concept that offers high process security due to the TXN insert and iLock tip seat interface. The tool is rigid, easy to use and the flexibility is high due to the large adjustability.
Benefits
- Less downtime in production thanks to overnight tool delivery
- Easy to apply
- High machine utilization
- Improved flexibility thanks to a large programme with large radius adjustability
Gun drills
-
Highly productive gun drills
In the machining world, drilling depths of 10 times the diameter and deeper are classified as deep hole drilling operations, whereby smaller drilling depths can also be produced with the help of gun drills. The positive effects of the gun drilling process are good surface quality, optimized alignment accuracy and low concentricity deviation.
Gun drills from Sandvik Coromant are easy to use and require no pre-setting. Depending on the application, we offer several different types of gun drills to fulfill your machining requirements.
Drills for composites
CoroDrill® ® 452
-
Close-tolerance hole making in composite materials
For aerospace rivet and bolt holes, you can’t go wrong with this assortment of new standard drills. Each carbon fibre material can be different which then varies the risk for delamination or splintering. These drills, optimized for composite- and metallic-stack materials, ensure the stringent hole tolerances are met with exceptional finish and quality.
Benefits
- Close hole tolerances, good surface finish
- Tools optimized by CFRP and metallic-stack material type
- Low-thrust geometries reduce risk of hole delamination and burrs
CoroDrill® ® 854/856
-
Solid carbide drills for high quality hole making in composite
Producing holes in high resin materials, with increasing demands on delamination and spintering, can be optimized with the drill geometry design.
The CoroDrill geometries is designed to improve hole entrance and exit quality on carbon fibre materials with high fibre content.
Benefits
- Excellent hole quality and surface finish
- Reduced risk for delamination and splintering
- Reduced burr formation on exit in aluminium materials (CD854)
Exchangeable tip drills
CoroDrill® ® 870
-
Secure and predictable holemaking process
Designed for the intermediate hole-tolerance area of H9–H10, the CoroDrill® 870 exchangeable-tip drill saves time and reduces your cost per hole. CoroDrill 870 can be tailored to opimize applications through diameter range, steps and length possibilities. Holes can be made more efficiently and closer to the specifications required, leaving them better suited to subsequent operations
Benefits
- Reliable and secure process
- Easy handling and secure tip changing
- Optimized chip control and evacuation
- Long predictable tool life and high productivity
- Low cost per hole and excellent hole quality
Gun drills
Gun drills
-
Highly productive gun drills
In the machining world, drilling depths of 10 times the diameter and deeper are classified as deep hole drilling operations, whereby smaller drilling depths can also be produced with the help of gun drills. The positive effects of the gun drilling process are good surface quality, optimized alignment accuracy and low concentricity deviation.
Gun drills from Sandvik Coromant are easy to use and require no pre-setting. Depending on the application, we offer several different types of gun drills to fulfill your machining requirements.
Indexable drills
CoroDrill® 880
-
Indexable insert drills
Indexable drills have long been known for their cost-efficiency—but lower price tags often come at the expense of accuracy and hole quality. The CoroDrill® 880 solves this problem with unique insert geometries and a configuration that creates a balanced, step-by-step entrance into the workpiece. This reduces cutting forces to less than half of typical insert drills, and virtually eliminates deflection on entry.
CoroDrill® 880 range features indexable insert drills from 12 to 84 mm (0.472-3.307 inch) in diameters, as well as engineered solution to 129 mm (5.078 inch). Products are available in two different designs to cover different diameter ranges.
For hole diameters 12.00−63.50 mm (0.472−2.500 inch)
CoroDrill 880 indexable insert drill
For hole diameters 65.00−84.00 mm (2.559−3.307 inch)
CoroDrill 880 indexable insert drill for large diameter holes
Complementary product for unstable conditions and non-rotating applications CoroDrill 881
CoroDrill® 881
-
Secure holemaking for smaller diameters
A problem solver for holes below 24 mm (0.945 inch) diameter. This complementary tool is optimized for unstable conditions, providing increased process security and stability for smaller hole diameters.
Benefits
- Excellent choice for unstable conditions
- Robust drill-body concept and insert design
- Good choice for non-rotating applications
- Easy to use
Coromant U
-
Indexable insert plunge drill
Plunge drilling is an effective method for roughing out cavities. It makes a deeper hole or cavity through repeated axial cuts. Coromant U drill can be used in broad machining conditions.
Benefits
- High tool body strength enables demanding plunge drilling operations
- Power efficient, productive solution with high metal removal rate
T-Max U stack drill
-
Productive stack drilling
T-Max U stack drill is optimized for stack drilling – a method used for drilling large numbers of holes through thin plates. When the drill breaks through a stacked plate, it creates a minimal disc that is evacuated along the chip channel.
Benefits
- Productive stack drilling
- Efficient chip evacuation
Reamers
CoroReamer 435
-
High speed precision reaming
CoroReamer™ 435 is a multi-application, versatile and high speed reamer, suitable for a wide range of materials. It gives you really close hole tolerances and high-quality surface finish thanks to internal coolant, the cutting edge geometry and extremely unequal spacing of the cutting edges.
Benefits
- High productivity due to high cutting parameters
- Consistency and productivity saving time and costs
- Excellent surface finish on the component
- Uniform concentricity for long tool life and dimensional accuracy
- High stability due to the solid carbide body
- Internal coolant for better chip evacuation and reduced wear
CoroReamer 830
-
High feed precision tool for through holes
CoroReamer® 830 is a modular designed tool with replaceable cutting head, easy to change while still in the machine tool spindle. The cutting head is located in the holder by a precision made tapered coupling for highest concentricity and repeatability with a radial run-out of 3µm (120µinch)
Benefits
- High surface finish and operation security
- High penetration rate
- Fast and easy head change with high accuracy < 3µm (120µinch)
CoroReamer 835
-
High performance precision reaming
CoroReamer™ 835 is optimized for ISO P and ISO M materials. Internal coolant and extremely unequal spacing of the cutting edges are two features that promise really close hole tolerances and high-quality surface finish.
Benefits
- High productivity due to high cutting parameters
- Consistency and productivity saving time and costs
- Excellent surface finish on the component
- Uniform concentricity for long tool life and dimensional accuracy
- High stability due to the solid carbide body
- Internal coolant for better chip evacuation and reduced wear
Solid carbide drills
CoroDrill® 460
-
Versatile high-performance drill
CoroDrill® 460 -XM is a multi-application, high performance drill that can be used across a wide range of materials. This drill provides high capacity utilization, flexibility and versatility. With one drill for all materials, stock holding can be reduced and greater machine flexibility is offered leading to reduced set-up time.
Benefits
- High productivity and consistent tool life
- Exceptional value with no compromise on quality
- Excellent hole quality
- Outstanding coating and flute design leading to smooth and efficient chip evacuation
- Reduced tooling costs
- Can be reground up to three times, extending tool life even further
CoroDrill® 860
-
High performance drills optimized for steel, stainless steel and aluminium
CoroDrill® 860 is a solid carbide drill designed for a fast and problem-free drilling. It maximizes productivity through high metal cutting efficiency and machine utilization. With excellent chip evacuation in long and short chipping materials, CoroDrill 860 provides green light machining at high penetration rates.
The CoroDrill 860 product offer consists of three drill geometries – optimized for steel, stainless steel and aluminium. The drill comes in lengths 3 – 8×D as standard. Extended assortment is available as Tailor Made.
Benefits
- Optimized cutting data
- Low cost per hole
- Improved performance reliability
- Trouble-free chip evacuation
- Long tool life, controlled wear formation
- Consistent hole tolerance
CoroDrill® 861
-
Solid carbide deep hole drills
CoroDrill® 861 provides the high stability essential for drilling deep holes, with high speed and efficiency.
Benefits
- Accurate deep holes to depths up to 30 × drill diameter, without pecking
- High speeds and feeds allow greater productivity to reduce cost per hole
- Fast and efficient chip evacuation reduces machine downtime and increases tool life
CoroDrill® 862
-
Solid carbide micro drills
CoroDrill® 862 offers outstanding performance for holes up to 2.95 mm (0.116 inch) diameter. A thin, effective coating helps retain cutting edge geometry and provide a smooth surface for chip evacuation, while even wear formation prolongs tool life for a wide range of materials.
Benefits
- High performance in steel, stainless steel, cast iron and aluminium
- Engineered tool geometry and surface treatment for efficient chip removal
- Good hole entry and exit, tight hole tolerance
CoroDrill® R840
-
Solid carbide drill for highly productive hole making
CoroDrill® R840 is a solid carbide drill for productive hole making in various applications. Designed for superior drilling in all materials, including hard steels up to 60 HRC. Available in a variety of diameters for general and small part machining.
Benefits
- Secure and predictable solution with minimized run-out
- Close hole tolerances
- Regrindable
- Suitable for a large range of materials
CoroDrill® R846
-
Optimized drilling in heat resistant super alloys
When drilling in heat resistant super alloys many things need to be taken into account. Process security is the most important criteria along with repeatability, hole tolerance and quality. CoroDrill R846 delivers this using a unique geometry, a high-quality edge line and a wear-resistant top coating.
Benefits
- Reliability and process security
- Predictable tool life
- Excellent repeatability
- An industry accredited product with high quality reconditioning service
Trepanner
T-Max® U
-
Indexable insert plunge drill
Coromant U drill could be used in broad machining conditions. High tool body strength enables demanding plunge drilling operations
- Centre- and periphery-insert
- Geometries and grades for all materials
- Wiper geometry for best surface finish
- Engineered special options diameter range available
Boring tools
Face grooving
CoroBore® ® 825 SL face grooving
-
Productive face grooving
Machining grooves with CoroBore® SL is a productive alternative to milling grooves. This fine-adjustable axial face grooving tool machines grooves in a large number of components and diameters.
Benefits
- Increased productivity compared to milling
- Excellent chip control thanks to internal coolant to the cutting edge
- Builds on our large assortment of standard SL32 blades and CoroCut system 1-2 inserts
- Radial fine-adjustable face grooving heads for pre-setting
CoroBore® ® XL
-
Large diameter boring system
The CoroBore® XL system is a group of large diameter boring tools. The wide application range covers rough and fine boring, interpolation turning as well as face grooving and the unique SpiroGrooving™ method.
Benefits
- Reliable system with rigid interfaces between head and cartridge for stable and vibration-free boring
- Dedicated cartridges designed for highest stability
- Dedicated tool holders optimized for large diameter machining
- Internal coolant through the tools to the cutting edge
Fine boring
CoroBore® 824 XS
-
New boring concepts
Boring small-diameter holes even at long overhangs has never been easier. Sandvik Coromant is now expanding the fine boring offer with new boring concepts. CoroTurn XS boring bars and the exchangeable-head (EH) system make boring down to 1 mm (0.039 inch) diameter possible, while keeping your tool inventory at a minimum.
Benefits
- Increased accessibility with Coromant Capto and EH modular interfaces in small diameters
- Boring with solid carbide boring bars reduces vibration and increases stability when working with long overhangs
- Boring bars with indexable inserts and diameter adjustability increase tooling flexibility while reducing tool investment and inventory costs
CoroBore® 825
-
Fine boring tool for high precision boring
CoroBore® 825 is the first choice for all fine boring operations. The tools can be adjusted radially in order to cover a certain diameter range with one tool. The tools allow precision adjustment in microns in order to achieve close tolerances.
Benefits
- Flexible solutions linking to any machine interface; choose between Coromant Capto and EH modular interfaces
- Achieve required overhang even at small diameters with the EH modular system
- Reliable system with rigid interfaces between head and cartridge for stable and vibration-free boring
- Diameter adjustment by 0.002 mm (0.00008 inch) for high accuracy
- Excellent surface finish with wiper inserts
- Close hole tolerances of IT6
- Available as dampened tool for vibration-free boring even at long overhangs
CoroBore® 825/826 XL
-
Fine boring tool for large diameters
CoroBore® 825 XL and CoroBore® 826 XL are the first choices for large diameter fine boring. The tools can be adjusted radially in order to cover a certain diameter range with one tool. The tools allow precision adjustment in microns in order to achieve close hole tolerances.
Benefits
- Reliable system with rigid interfaces between head and cartridge for stable and vibration-free boring
- Dedicated grades and geometries for all materials
- Excellent surface finish with wiper inserts
- Dedicated tool holders optimized for large diameter boring
- Close hole tolerances
- Available as dampened tool (silent tools) for vibration-free boring in diameter 150-315 mm (5.906-12.402 inch) for fine boring even at long overhangs
- Also available as lightweight tools: CoroBore lightweight boring tools reduce tool weight and tool change moment, making handling easier and larger diameters possible
Fine boring head
-
391.37A/B fine-adjustable head for small-diameter boring and face grooving
The versatile 391.37A/B system can be used for both fine boring and face grooving applications. It allows precision adjustment in microns in order to achieve close hole tolerances. Build modular assemblies with Coromant Capto® or HSK for increased tooling flexibility. Fine-adjustable heads and sleeves
Benefits
- Choose between conventional (.37A) and high speed (.37B) fine-adjustable head
- Flexible solution for a broad diameter range
- Excellent surface finish with wiper inserts
- Close hole tolerances of IT6
CoroBore® XL
-
Large diameter boring system
The CoroBore® XL system is a group of large diameter boring tools. The wide application range covers rough and fine boring, interpolation turning as well as face grooving and the unique SpiroGrooving™ method.
Benefits
- Reliable system with rigid interfaces between head and cartridge for stable and vibration-free boring
- Dedicated cartridges designed for highest stability
- Dedicated tool holders optimized for large diameter machining
- Internal coolant through the tools to the cutting edge
Rough boring
CoroBore® 820
-
Rough boring tool with three insert design
CoroBore® 820 is your first choice for rough boring. The comprehensive program of tool bodies, slides, shims and cutting inserts allow CoroBore 820 to be configured to suit the widest possible range of applications. The same programme can be utilized for productive boring, step boring and single edge boring. The system consists of adaptors with matching slides, shims and covers, making it possible to adapt the tool to various materials and conditions.
Benefits
- Versatile with three different operation types in one tool
- Large standard assortment of CoroTurn 107 and T-Max P inserts
- High metal removal rate due to three insert design
CoroBore® 820 XL
-
Rough boring tool for large diameter boring
CoroBore® XL is the boring tool system for large diameter boring. The bridges and holders enable rough boring to be completed with high productivity. The system gives a more rigid and reliable performance in larger bores, and is designed to generate the required hole quality and diameter.
Benefits
- Reliable system with rigid interfaces between head and cartridge for stable and vibration free boring
- Dedicated cartridges designed for highest stability
- Dedicated tool holders optimized for large diameter boring
- Also available as lightweight tools: CoroBore lightweight boring tools reduce tool weight and tool change moment, making handling easier and larger diameters possible
DuoBore® 821/821D
-
Rough boring tool with two insert design
DuoBore™ 821 is a versatile rough boring tool that can be used in three different operation types: multi edge- , step- and single edge boring. The slides can be adjusted individually, both axially and radially. The system consists of adaptors with matching slides, shims and covers, making it possible to adapt the tool to various materials and conditions.
CoroBore® XL
-
Large diameter boring system
The CoroBore® XL system is a group of large diameter boring tools. The wide application range covers rough and fine boring, interpolation turning as well as face grooving and the unique SpiroGrooving™ method.
Benefits
- Reliable system with rigid interfaces between head and cartridge for stable and vibration-free boring
- Dedicated cartridges designed for highest stability
- Dedicated tool holders optimized for large diameter machining
- Internal coolant through the tools to the cutting edge
Silent Tools
Silent Tools for boring
-
The vibration solution for productive boring operations
Problems that originate from vibrations are frequently encountered in boring and other operations, especially when machining with long overhangs. The vibrations may cause bad surface texture, insufficient accuracy, loss of productivity, increased insert and machine tool wear, as well as noise.
Solving vibration problems will therefore always give you a productivity boost.
Benefits
- Productivity gains of 50-200%
- Improved surface finish
- Improved process security
- Reduced cost per component
Threading tools
Thread milling
CoroMill® 325
-
Thread whirling cutter for threading of long slender components
The growing use of medical bone screws, implants and other micro-components creates a need for techniques that produce special thread forms quickly and at high tolerances.
CoroMill® 325 thread whirling inserts and holders from Sandvik Coromant meet this need for a large number of sliding head machine types. They can thread long, slender components from rough stock at high speeds and produce a wide range of high precision screws and implants without the need for a dedicated thread whirling machine.
Benefits
- Increased productivity
- Chip control
- Increased tool life
- Cost saving
- High quality threads
- One grade for all materials
CoroMill® 326
-
Internal threading and chamfering in small holes
Versatile and cost efficient, this miniature milling cutter benefits from three cutting edges for internal threading and chamfering. Use it in small holes, down to 6 mm (0.236 inch) as a complement to CoroMill 327, CoroMill 328 and CoroMill Plura.
Benefits
- Three cutting edges for productivity
- Chamfering and back-chamfering of holes with one tool
- Very high precision and low cutting forces
- Same tool for different pitches
- One grade for all materials
CoroMill® 327
-
Groove- and thread milling cutters
A versatile cutter which can be used for many types of grooves, threads and chamfers; machining of eccentric components such as gearbox casings, and high volume assemblies, mainly in machining centres and rotating units in lathes.
Benefits
- Low cutting forces
- Sharp cutting edges for high quality grooves without burr
- Multiple edges for highly productive and economic machining
- Large programme with different shank lengths and diameters
- Large programme of inserts covering for instance circlips, o-rings, slots and threads
CoroMill® 328
-
Grooving, threading and circlip grooving
A versatile cutter which can be used for many types of grooves, threads and chamfers; machining of eccentric components e.g. gearbox casings, and high volume assemblies, mainly on machining centres and rotating units on lathes.
Benefits
- Inserts mounted in pockets for safe and stable mounting
- Economical insert with three edges
- Large programme of inserts covering circlips, slots, threads, etc.
- Low cutting forces
- Sharp precision-ground insert
- Different thread pitches possible with one tool
- Excellent for both internal and external machining
CoroMill® Plura
-
Solid end mills, tipped end mills and thread mills
In our comprehensive range of CoroMill® Plura end mills, you find your choice, whether you need a tool that is optimized for a specific material or one that performs well in many materials.
The range of tools includes high-performance solutions for high speed machining, die-making and high feed machining; from heavy roughing to super-finishing in most materials, whether it is in difficult-to-cut materials or very hard steels, up to 63 HRc.
The CoroMill Plura offer
- Optimized tools with geometries and grades for specific materials and applications, maximizing production output per time unit.
- Flexible tools designed for high performance and secure machining in avariety of materials, applications, component sizes and shapes, allowing maximum machine utilization.
Thread turning
CoroCut® MB
-
For internal machining of high precision components
CoroCut® MB is a high precision system for grooving, face grooving, profiling and pre-parting. The edge line of the cutting edge is sharp with a thin-layered coating, which in combination with the stability of the tools makes it ideal for internal machining.
Benefits
- Vibration free machining
- Fast set up for both tool and insert
- Stable high precision interface between interface and tool holder
CoroCut® XS
-
Versatile small part machining system for external applications
CoroCut® XS is a tangentially mounted system for precision machining in sliding head machines. The system is for external parting, grooving, turning, backturning and threading applications. The extremely sharp cutting edges perform best at low feeds.
Benefits
- High precision
- Close tolerances
- Easy indexing
- Good accessibility when changing inserts
- Wide variety of insert widths
- Internal grooving at very small diameters
CoroThread® 266
-
Ultra-rigid thread turning for all types of threads – internal and external
CoroThread® 266 is designed with an iLock interface to combat the extreme forces placed upon the insert in the threading operations. The tool guarantees excellent insert stability for ultimate accuracy, surface finish and product consistency.
Benefits
- Reduced machine- and downtime
- Excellent surface finish due to the exceptional stability
- High product consistency
- Three sharp cutting edges for high-quality threads
- Multi-point inserts available, require fever passes resulting in increased productivity
CoroTurn® SL
-
Modular tooling system of adaptors with exchangeable cutting heads
CoroTurn® SL is a universal modular system of adaptors with exchangeable cutting heads where you can build customized tools for a variety of machining applications.
Flexible tooling
The ingenious Serration Lock (SL) interface is extremely robust and lets you create a wide range of tool combinations from a small inventory of adaptors and cutting heads
Adaptors available for both internal and external machining
Reliable chip evacuation and long tool life
The high precision nozzles on the cutting heads put coolant exactly where you need it, for good chip breaking and long tool life
Tool wear is mainly on the exchangeable cutting head, extending the life of the adaptor
High machine utilization
Quick change with Coromant Capto®
Adaptors with internal coolant for efficient coolant supply
CoroTurn® XS
-
Internal machining of small high quality features
CoroTurn XS precision ground tools are perfect when producing small internal features with high quality. The large variety of adaptors fit most types of sliding head machines and the solid carbide boring bars are designed for exact cutting edge position, enabling high precision and repeatability.
Benefits
- Optimized for machining of small high quality features
- High precision and repeatability
- Reliable and easy-to-use clamping system
T-Max Twin-Lock®
-
External and internal threading for the oil & gas industry
T-Max Twin-Lock® is designed for the oil & gas industry, primarily in areas of high volume, such as threading in tubing, casing and coupling production. It also covers connection threads where indexing accuracy, reliability of insert edge and repeatability are essential.
Benefits
- Productive threading with multi-tooth inserts
- Excellent indexing accuracy and repeatability
- Edge security
T-Max U-Lock®
-
Internal threading
T-Max U-Lock® is a complement to the CoroThread 266 rigid indexable insert threading system. It provides a specialized solution for 11 mm (0.433 inch) internal threading applications in three different geometries: all-round, sharp and a chip breaking C-Geometry.
Benefits
- Cost efficient solution with three cutting edges
- Tailor Made inserts available
Tapping tools
Cutting taps
CoroTap® 100
-
Straight flute tap
Straight flute taps are mainly used for short chipping materials like cast iron and are suitable for both through and blind holes. The flute is mainly used for cutting fluid but with internal coolant, chip evacuation is also possible.
Features
- Chamfer C (2-3 threads) and chamfer E (1.5-2 threads). Chamfer E only for ISO K materials used in blind holes with low clearance
- High speed powder steel taps for improved strength, wear resistance and tool life
- Solid carbide taps for superior tool life and highest productivity
- Taps with interrupted threads for ISO N materials to reduce torque
- CoolTop coating combines high hardness with good wear resistance
CoroTap® 200
-
Spiral point tap
Spiral point taps push the chips forward and are used for through holes. They have the strongest tap design due to shallow flutes. The flutes are only used for cutting fluid, not for chip evacuation.
Features and benefits
- Chamfer B (3.5-5 threads) for high process security
- Edge treatment for reduced axial force and torque makes the tool run more smoothly, reduces risk of cutting-edge chipping and improves surface quality, tool life and chip formation
- High speed powder steel taps for improved strength, wear resistance and tool life
- Different coatings and grades are available:
- CoolTop coating combines high hardness with good wear resistance
- SmoothTop coating for low friction and adhesion
- Steam Temp An oxide layer protects the surface, act as a good carrier of lubricants and prevents cold welding and built-up edge
CoroTap® 300
-
Spiral flute tap
Spiral flute taps are the best option for blind holes. The flute transports the chips out of the hole and is also used for cutting fluid. There are different helix angles suitable for different applications.
Features and benefits
- Chamfer C (2-3 threads) and Chamfer E (1.5 - 2 threads)
- Edge treatment for reduced axial force and torque, makes the tool run more smoothly, reduces risk of cutting-edge chipping and improves surface quality, tool life and chip evacuation
- The design of the spiral flute secures a constant rake angle and gives a constant cutting process
- Back chamfer, used on taps with high helix angle, reduces torque and chipping
- Taps with high spiral angle give excellent chip evacuation and possibilities to thread up to 3 × diameter in blind holes
- Taps with low spiral angle give strong edges and are suitable for tapping tough materials, generating short chips in blind holes
- High speed powder steel taps for improved strength, wear resistance and tool life
- Solid carbide taps for long tool life and high productivity
- Different grades and coatings are available:
- CoolTop coating combines high hardness with good wear resistance
- SmoothTop coating for low friction and adhesion
- Steam Temp An oxide layer protects the surface, act as a good carrier of lubricants and prevents cold welding and built-up edge
Forming taps
CoroTap® 400
-
Forming tap
Forming taps form the thread instead of cutting. This is a chip-free solution that is suitable for both through and blind holes. All materials are not suitable since there is need of certain ductility; recommended tensile strength limit is 1200 N/mm2. Forming taps are available with and without oil grooves.
Features
- Chamfer C (2-3 threads) and chamfer E (1.5-2 threads). Chamfer E mainly used in blind holes with low clearance
- High speed powder steel taps for improved strength, wear resistance and tool life
- Solid carbide taps for superior tool life and highest productivity
- Three different coatings are available:
- TiCN – used on our solid carbide forming taps. Combines low friction with high hardness
- TiN – all-round coating with low friction
- CrN – excellent for ISO N materials and low alloyed steel
Tooling systems
Machining centers
BIG-PLUS®
-
Improved stability with BIG-PLUS®
BIG-PLUS® spindle system* is adopted by a large number of machining centres and many machine-tool builders have recognized this system for its excellent performance. BIG-PLUS is a dual-contact system that provides taper and flange contact when tool holders are clamped into the spindle.
The BIG-PLUS solid holder assortment consists of Machine interface adaptor, Face mill, Combi Weldon/ISO9766 holders , CoroChuck™ 930 and ER collet chucks. Choose solid holders when there is a small need for flexibility in high batch production.
Benefits
- Improved stability leads to minimized vibration
- Greater bending stiffness allows for higher cutting data, hence higher productivity
- Enhanced rigidity thanks to simultaneous fit of taper and flange
Modular system – Coromant EH
-
Tooling flexibility for small diameters
The exchangeable-head system, Coromant EH, includes a wide assortment of solid carbide heads, indexable milling cutters, boring heads, integrated machine adaptors and different shanks.
The modular EH design delivers great advantages in large machining centres requiring long reach as well as in small to medium-sized machining centres and turning centres having critical gauge length.
Benefits
- Great tooling flexibility – choose from an extensive variety of heads, adaptors and shanks
- Reduced tool inventory with standardized tools minimizing machine downtime
- Excellent tool utilization and easy handling thanks to the reliable and accurate coupling between head and shank
- The high rigidity of the short tool assembly makes it possible to increase cutting depths without losing stability
CoroChuck™ 930
-
High-precision hydraulic chuck with high pull-out security and precision
With the best pull-out security on the market this chuck is designed to eliminate vibration for excellent stability and accessibility in all milling and drilling operations. Covering all machine interfaces, CoroChuck™ 930 helps to maintain efficient production through quick and easy tool set-ups and changes. Available even as Tailor Made option.
Benefits
- High metal removal rate provides increased productivity
- Secure process and safe machining
- Quick tool change and set-up
- Enhanced surface finish and increased tool life
- Close hole tolerance
CoroChuck™ 970
-
High-performance tapping chucks for a secure process
Since tapping operations are critical the security and quality is important. To achieve a top result, not only the tapping tool is important, but also the tool holder. The new versatile CoroChuck™ 970 is designed for a stable and precise tapping process in all materials.
Benefits
- Improves tapping tool life
- Secure machining process
- Reduces the risk of cutting oversized threads significantly
Coromant Capto®
-
Three systems in one
Coromant Capto® is a modular quick change tooling concept offering three systems in one:
Quick change tool holders for turning centres reduce set-up and tool change time, leading to significantly increased machine utilization Coromant Capto directly integrated in the spindle increases stability and versatility in e.g. multi-task machines, machining centres with turning capability and vertical lathes
Coromant Capto as a modular system for machining centres offers a large variety of extension- and reduction adaptors, enabling assembling of tools with different lengths and design characteristics regardless of the machine interface (SK, HSK, Big Plus). The modularity function means less need for expensive special tools with long delivery times
The same tools can thus be used in the entire workshop, providing unique flexibility, optimal rigidity and minimized tool inventory.
Benefits
- Flexible with extensive modularity
- High basic stability and accuracy
- Minimized tool inventory
- Reduced set-up time
HSK
-
Solid tool holding system
Sandvik Coromant offers a broad assortment of HSK solid and modular tool holding systems that can be used in spindles with both automatic and manual tool change. Properly applied, HSK offers high consistency in terms of radial and axial accuracy.
Benefits
- Consistent performance
- Light tools compared to ISO-tapers
- Common rotating interface
Multi-task machines
Coromant EH
-
Tooling flexibility for small diameters
The exchangeable-head system, Coromant EH, includes a wide assortment of solid carbide heads, indexable milling cutters, boring heads, integrated machine adaptors and different shanks.
The modular EH design delivers great advantages in large machining centres requiring long reach as well as in small to medium-sized machining centres and turning centres having critical gauge length.
Benefits
- Great tooling flexibility – choose from an extensive variety of heads, adaptors and shanks
- Reduced tool inventory with standardized tools minimizing machine downtime
- Excellent tool utilization and easy handling thanks to the reliable and accurate coupling between head and shank
- The high rigidity of the short tool assembly makes it possible to increase cutting depths without losing stability
CoroChuck™ 930
-
High-precision hydraulic chuck with high pull-out security and precision
With the best pull-out security on the market this chuck is designed to eliminate vibration for excellent stability and accessibility in all milling and drilling operations. Covering all machine interfaces, CoroChuck™ 930 helps to maintain efficient production through quick and easy tool set-ups and changes. Available even as Tailor Made option.
Benefits
- High metal removal rate provides increased productivity
- Secure process and safe machining
- Quick tool change and set-up
- Enhanced surface finish and increased tool life
- Close hole tolerance
CoroChuck™ 970
-
High-performance tapping chucks for a secure process
Since tapping operations are critical the security and quality is important. To achieve a top result, not only the tapping tool is important, but also the tool holder. The new versatile CoroChuck™ 970 is designed for a stable and precise tapping process in all materials.
Benefits
- Improves tapping tool life
- Secure machining process
- Reduces the risk of cutting oversized threads significantly
Coromant Capto®
-
Three systems in one
Coromant Capto® is a modular quick change tooling concept offering three systems in one:
Quick change tool holders for turning centres reduce set-up and tool change time, leading to significantly increased machine utilization Coromant Capto directly integrated in the spindle increases stability and versatility in e.g. multi-task machines, machining centres with turning capability and vertical lathes
Coromant Capto as a modular system for machining centres offers a large variety of extension- and reduction adaptors, enabling assembling of tools with different lengths and design characteristics regardless of the machine interface (SK, HSK, Big Plus). The modularity function means less need for expensive special tools with long delivery times
The same tools can thus be used in the entire workshop, providing unique flexibility, optimal rigidity and minimized tool inventory.
Benefits
- Flexible with extensive modularity
- High basic stability and accuracy
- Minimized tool inventory
- Reduced set-up time
CoroPlex® MT
-
Multifunctional milling and turning tool
CoroPlex® MT is a combination of two winning concepts in one – CoroMill® 390 and CoroTurn® 107. It is either applied rotating as an efficient tool for milling applications, or indexed in a number of optional positions for stationary turning, external and internal, using two different CoroTurn 107® inserts.
Benefits
- One milling and four turning tools in one
- Reduced tool changing time
- Saves tool pockets in tool magazine
- Stationary application as a turning tool, external or internal
CoroPlex® TT
-
Two turning tools in one
CoroPlex® TT is a twin tool with great flexibility. With two turning inserts on the same tool, substantial tool changing time is saved. CoroPlex TT gives you a variety of solutions for most turning operations.
Benefits
- One milling and four turning tools in one
- Reduced tool changing time
- Saves tool pockets in tool magazine
HSK
-
Solid tool holding system
Sandvik Coromant offers a broad assortment of HSK solid and modular tool holding systems that can be used in spindles with both automatic and manual tool change. Properly applied, HSK offers high consistency in terms of radial and axial accuracy.
Benefits
- Consistent performance
- Light tools compared to ISO-tapers
- Common rotating interface
Machine adapted clamping units
-
Machine adapted clamping units — MACU
These clamping units and driven tool holders are designed to fit specific turret interfaces, with unique bolt patterns for each machine brand. Quick change Coromant Capto® clamping units provide unrivalled performance, ensuring high machine utilization through reduced set-up and production time.
Applications:
- Turning — two-axis and four-axis
- Multi-task machines
Turning centers
Coromant EH
-
Tooling flexibility for small diameters
The exchangeable-head system, Coromant EH, includes a wide assortment of solid carbide heads, indexable milling cutters, boring heads, integrated machine adaptors and different shanks.
The modular EH design delivers great advantages in large machining centres requiring long reach as well as in small to medium-sized machining centres and turning centres having critical gauge length.
Benefits
- Great tooling flexibility – choose from an extensive variety of heads, adaptors and shanks
- Reduced tool inventory with standardized tools minimizing machine downtime
- Excellent tool utilization and easy handling thanks to the reliable and accurate coupling between head and shank
- The high rigidity of the short tool assembly makes it possible to increase cutting depths without losing stability
CoroChuck™ 930
-
High-precision hydraulic chuck with high pull-out security and precision
With the best pull-out security on the market this chuck is designed to eliminate vibration for excellent stability and accessibility in all milling and drilling operations. Covering all machine interfaces, CoroChuck™ 930 helps to maintain efficient production through quick and easy tool set-ups and changes. Available even as Tailor Made option.
Benefits
- High metal removal rate provides increased productivity
- Secure process and safe machining
- Quick tool change and set-up
- Enhanced surface finish and increased tool life
- Close hole tolerance
CoroChuck™ 970
-
High-performance tapping chucks for a secure process
Since tapping operations are critical the security and quality is important. To achieve a top result, not only the tapping tool is important, but also the tool holder. The new versatile CoroChuck™ 970 is designed for a stable and precise tapping process in all materials.
Benefits
- Improves tapping tool life
- Secure machining process
- Reduces the risk of cutting oversized threads significantly
Coromant Capto®
-
Three systems in one
Coromant Capto® is a modular quick change tooling concept offering three systems in one:
Quick change tool holders for turning centres reduce set-up and tool change time, leading to significantly increased machine utilization Coromant Capto directly integrated in the spindle increases stability and versatility in e.g. multi-task machines, machining centres with turning capability and vertical lathes
Coromant Capto as a modular system for machining centres offers a large variety of extension- and reduction adaptors, enabling assembling of tools with different lengths and design characteristics regardless of the machine interface (SK, HSK, Big Plus). The modularity function means less need for expensive special tools with long delivery times
The same tools can thus be used in the entire workshop, providing unique flexibility, optimal rigidity and minimized tool inventory.
Benefits
- Flexible with extensive modularity
- High basic stability and accuracy
- Minimized tool inventory
- Reduced set-up time
CoroTurn® SL
-
Modular tooling system of adaptors with exchangeable cutting heads
CoroTurn® SL is a universal modular system of adaptors with exchangeable cutting heads where you can build customized tools for a variety of machining applications.
Flexible tooling
The ingenious Serration Lock (SL) interface is extremely robust and lets you create a wide range of tool combinations from a small inventory of adaptors and cutting heads
Adaptors available for both internal and external machining
Reliable chip evacuation and long tool life
The high precision nozzles on the cutting heads put coolant exactly where you need it, for good chip breaking and long tool life
Tool wear is mainly on the exchangeable cutting head, extending the life of the adaptor
High machine utilization
Quick change with Coromant Capto®
Adaptors with internal coolant for efficient coolant supply
EasyFix
-
Sleeves for correct mounting of cylindrical bars, also for high coolant pressure
EasyFix sleeves are a solution for cylindrical boring bars reducing set-up time. A spring plunger mounted in the sleeve clicks into a groove in the bar to guarantee the correct centre height.
The slot in the cylindrical sleeve is metallic sealed which allows the existing coolant supply system to be used. The metallic sealing offers good performance also for high coolant pressure.
Benefits
- Fast set-up time
- Simple to use
- Extended tool life
- Excellent surface finish
Machine adapted clamping units
-
Machine adapted clamping units — MACU
These clamping units and driven tool holders are designed to fit specific turret interfaces, with unique bolt patterns for each machine brand. Quick change Coromant Capto® clamping units provide unrivalled performance, ensuring high machine utilization through reduced set-up and production time.
Applications:
- Turning — two-axis and four-axis
- Multi-task machines
Small part machines
Coromant EH
-
Tooling flexibility for small diameters
The exchangeable-head system, Coromant EH, includes a wide assortment of solid carbide heads, indexable milling cutters, boring heads, integrated machine adaptors and different shanks.
The modular EH design delivers great advantages in large machining centres requiring long reach as well as in small to medium-sized machining centres and turning centres having critical gauge length.
Benefits
- Great tooling flexibility – choose from an extensive variety of heads, adaptors and shanks
- Reduced tool inventory with standardized tools minimizing machine downtime
- Excellent tool utilization and easy handling thanks to the reliable and accurate coupling between head and shank
- The high rigidity of the short tool assembly makes it possible to increase cutting depths without losing stability
QS™ holding system
-
Get more out of your sliding head machine
QS™ holding system is a quick change tool holder for maximized machine utilization in sliding head machines. The system is available with high precision coolant for excellent process security.
Easy tool change for reduced downtime
Single screw release of holder simultaneously pulls out the wedge, for easy tool change and set-up
Spring clamping mechanism of the wedge eliminates the risks of tool holder dropping into the machine
No diameter adjustment is necessary thanks to the back stop – close repeatability tolerance for insert edge position
QS holding system can be quickly mounted on the machine with no reconstruction
Process security with high precision
- High precision coolant improves chip control, tool life and component quality
- The stable tool clamping adds secure insert edge position for good repeatability and accuracy
Application
- Turning, parting, grooving and threading of small components
- Sliding head machines
- Available for Citizen, Star, Tsugami, Hanwha, Tornos and Nexturn machines
Silent Tools
Silent Tools for tool holding
-
Silent Tools for tool holding
Silent Tools is the trademark for a family of tool adaptors for turning, milling and boring. The tool adaptors are designed to minimize vibrations through a dampener inside the tool. The majority of Silent Tools customers’ use these tools for long overhangs however, even with shorter overhangs, large productivity increases and surface quality improvements are to be gained.
Whether you increase your metal removal, improve your surface finish, secure your process or reduce your production costs you will certainly enjoy the silence.
