  • Offer Profile
  • We have been developing and producing high-grade labels for the cosmetics, pharmaceuticals, high-tech, food, beverages and tobacco, security and logistics industries for forty years. Working with our subsidiary etiroll and a highly efficient mechanical engineering department, we offer complete label printing, labelling and software application solutions to the entire industrial sector.

Product Portfolio
  • System

  • Labellers

  • Fully automatic labelling systems

  • etifix supplies the right answer to every labelling problem – from standardized through to individually bespoke solutions. Possible labelling techniques include roll-on/wipe-on methods, no-contact blow-on application and temp blow labelling – a technology permitting label application on a minimum of space. It goes without saying that all our labellers are designed for maximum durability and clarity of operation in compliance with CE standards.

    Fully automatic labelling systems
    • In-line (within a production line ) and off-line application possible
    • Communication capability via an SBS interface with upstream and downstream machines
    • Capacity for up to 72,000 labels/hour
    • Precise labelling with optimum reproduction accuracy
    • Modular design offers scope to address present and future labelling requirements whenever this is needed
    • Labelling possible on cylindrical, angular and oval shapes made of a wide range of materials
    • Facility for upgrading to include a print module (e.g. for batch numbers or use-by dates)
    • Fully automatic labelling system etifix 3114

    • Fully automatic labelling system etifix 9000

    • Fully automatic labelling system etifix 4138

  • Semi automatic labellers

  • etifix supplies the right answer to every labelling problem – from standardized through to individually bespoke solutions. Possible labelling techniques include roll-on/wipe-on methods, no-contact blow-on application and temp blow labelling – a technology permitting label application on a minimum of space. It goes without saying that all our labellers are designed for maximum durability and clarity of operation in compliance with CE standards.

    Semi-automatic labellers
    • Generally table-top devices
    • Application possible as part of a partially automated production line (manual feed and removal of labelled product)
    • Throughput of up to 1,500 labels/hour
    • Precise labelling with optimum reproduction accuracy
    • Modular design offers scope to address present and future labelling requirements whenever needed
    • In some cases offering facility for combination with label printers for real-time printing / application
    • Labelling possible on cylindrical, angular and oval shapes made of a wide range of materials
    • Facility for upgrading to include a print module (e.g. for batch numbers or use-by dates)
    • Semi-automatic labeller

    • Semi-automatic labeller

    • Semi-automatic labeller

  • Print and apply systems

  • etifix supplies the right answer to every labelling problem – from standardized through to individually bespoke solutions. Possible labelling techniques include roll-on/wipe-on methods, no-contact blow-on application and temp blow labelling – a technology permitting label application on a minimum of space. It goes without saying that all our labellers are designed for maximum durability and clarity of operation in compliance with CE standards.

    Print and apply systems
    • For real-time printing and real-time application of labels (to permit retracing production time / batch in compliance with product liability legislation)
    • Integration into any production line possible at short notice without preliminary assembly
    • Throughput up to 35,000 labels per hour
    • Precise labelling with optimum reproduction accuracy (in the micron range)
    • Modular design offers scope to address present and future labelling requirements whenever needed
    • Labelling in any position possible on cylindrical, angular and oval shapes made of a wide range of materials
    • Print and apply system etifix 3138 DAT

    • Print and apply system etifix 3138

  • etimat

  • Etifix has developed for the labelling of cylindrical objects the new etimat Vario series.
    Our easily manageable labelling system is available for fully-automatic and semi-automatic operation.
    The advantages of the etimat series are exact and dimensionally accurate labelling, a simple and intuitive handling, lower required space and the diversity of applied labelling goods.
    The first etimat Vario system has found its application in the labelling of cheese packets. The specially developed self adhesive label is applied accurate to dimension on the cheese packet. The self adhesive label has a perforation for a later date opening.
    The etifix etimat Vario series can also be used as a space saving table top labelling machine. Slightly modified the etifix etimat system can be used for the labelling of pots, tubes and ampullae.
    You can also receive the suitable labels for pots/jars, tubes and ampullae from us – etifix your partner for self adhesive labels and innovative labelling solutions.

    Details:
    The etimat labelling system is a modular construction system with following combinable assemblies:
    • labelling system with a labelling roll
    • Roadbed and pressing unit with electromagnetic and pneumatic lifting cylinder
    • mandrel to support unstable tubes
    • a specific component transport system for automatic loading and unloading of the labelling goods

    Technical performance data:
    • labelling system with a labelling roll
    • Roadbed and pressing unit with electromagnetic and pneumatic lifting cylinder
    • mandrel to support unstable tubes
    • a specific component transport system for automatic loading and unloading of the labelling goods
    • etimat vario EH

    • etimat vario EH

    • etimat vario EV tube

    • etimat vario EV print

  • Printers

  • Print your own individual etifix labels with our optimized printing systems.
    There are two printing methods to choose from:

    Thermal transfer printers
    The ink pigment (black) is transferred from a polyester liner coated with an ink layer onto the label using a thermal print head. This method produces a 100 per cent bond between the ink and the label surface. The result: an imprint that is scratch, abrasion and wipe-proof. etifix guarantees individual coordination between your label and the thermal transfer ribbon and printer.

    Thermal direct printers
    This technology eliminates the need for a ribbon. Instead, thermo-sensitive material is activated by the print head. This printing method is ideally suited for mass labelling if there are no stringent demands on quality, for example for price labels. Suitable for one-colour label printing.
    • Label printer

    • Label printer

    • Label printer

    • Label printer

  • accessories

  • We offer a wide selection of accessories to supplement the performance of our labellers and label printers. Blank labels and thermal transfer ribbons are naturally also available direct from us in the accustomed etifix standard of quality.
    • thermal transfer ribbons

    • auto splice unwinder

  • software

      • software

      • Standard software
        Our software solutions permit you to design your own labels and produce them in-house using etifix printers.
        Individual software
        We will be pleased to offer you individual software solutions tailored to your specific application requirements. We do this by using our software to integrate our labelling technology into the processes you use, thus ensuring an efficient work flow.
  • RFID & Auto-ID

  • RFID stands for radio frequency identification. This is a technology which permits the no-contact transmission of data using radio waves. It is ideal for use in applications such as:
    • Libraries
    • Ski passes
    • Admission tickets and many more
    Electronic product labelling is another important issue currently being debated.
    The benefits offered by RFID technology include:
    • Surveillance, optimization and acceleration of logistic processes
    • Enhanced product availability
    • Improved quality assurance (e.g. by monitoring sell-by dates)
    • No optical detection required
    • Information can be written on information carriers
    etifix provides a system integration service by designing and producing RFID labels, supplying and configuring the necessary scanning technology (bulk or individual detection) and providing software support: In other words, the entire scope of RFID-related services from a single, reliable source.

    Auto ID is an automatic identification facility using printed data carriers available in the form of a one-dimensional (optionally two-dimensional) printout. Once printed, the resulting code information can no longer be changed but only scanned to the maximum diagonal by optical reading devices.

    Applications:
    • EAN/UPC
    • Price labelling
    • Batch identification
    • Traceability
    • Part identification
    etifix provides a system integration service by supplying the bar code label (also consecutively numbered), the label printer, printer software and scanner for contact/no-contact scanning.
    • RFID

    • RFID

    • RFID

    • Auto-ID
